Command Protocol Reference Guide
A - 67
lpf_order Order Of Low-Pass Filter
Description
This parameter sets the order of the low-pass filter. Linkwitz-Riley filters only
support even orders. If an odd order is specified for a Linkwitz-Riley filter, it
will be internally rounded up to an even number.
lpf_type Type Of Low-Pass Filter
Description
This parameter sets the type of analog filter prototype used for the low-pass
filter.
Argument Argument value
Channel Type Virtual Channel
Value Type Integer
Read/Write Mode Read/Write
Phys Chans Conferencing Mic/Line Input, Conferencing Line Output,
Sound Reinforcement Mic/Line Input, Sound Reinforcement
Line Output, Analog Telephony Input, Analog Telephony
Output, Submix, ConferenceLink Aux Input, ConferenceLink
Aux Output
Virt Chans Mono, Stereo
System Limits Minimum: 1, Maximum: 8
Default 2
User Limits
Supported
No
Argument Argument value
Channel Type Virtual Channel
Value Type List
Read/Write Mode Read/Write
Phys Chans Conferencing Mic/Line Input, Conferencing Line Output,
Sound Reinforcement Mic/Line Input, Sound Reinforcement
Line Output, Analog Telephony Input, Analog Telephony
Output, Submix, ConferenceLink Aux Input, ConferenceLink
Aux Output
Virt Chans Mono, Stereo
Values butterworth : Butterworth filter (default)
linkwitz_riley : Linkwitz-Riley filter
